Application areas: DIY power banks, monitoring power supplies, children’s car power supplies, camera power supplies, car power supplies, communication equipment power supplies, various occasions with strict requirements for volume and weight (such as aviation models, etc.).
Product parameters:
Input voltage:4.75V-23V
Output voltage:1.0V-17V
Output current:3A (maximum), with a long interval of 1.8A
Conversion efficiency:96%
Output ripple:<30MV
Switching frequency:340KHz (maximum)
Working temperature:-40 ℃ -+85 ℃
Special Reminder:
1. The positive and negative terminals of the input and output terminals cannot be reversed, otherwise the module will be directly burned out;
2. The maximum input voltage and maximum output current cannot be met simultaneously, and high voltage, high current, and hot plugging should not be used for a long time. Attention should be paid to strengthening heat dissipation;
3. It is recommended to use the output power within 10W, please leave a margin for use;
4. This is a voltage reduction module where the input voltage is greater than the output voltage;
5. Onboard adjustable potentiometer, gently rotate to achieve voltage regulation effect.
