Specifications |
|
|
MCU |
ESP32-S3 |
|
Flash |
16MB |
|
PSRAM |
8MB |
|
Wireless Connectivity |
2.4Ghz Wi-Fi |
|
BLE 5 |
|
|
Onboard Functions |
|
|
Onboard Button |
Reset + Boot |
|
CC1101 Low-Power Sub-1 GHz RF Transceiver |
|
|
Frequency Bands |
|
|
Optional Expansion |
|
|
nRF24L01 |
Worldwide 2.4GHz ISM |
|
I2C Transceiver Module |
|
|
PN532 |
MAX98357A |
|
Screen Specifications |
|||
|
Type |
IPS TFT LCD |
Resolution |
170(H)RGB x 320(V) |
|
Drive Chip |
ST7789 |
Size |
1.9-inch Diagonal |
|
Interface |
SPI |
||
|
Version Differences |
||
|
Version |
T-Embed |
T-Embed PLUS |
|
CC1101 |
YES |
YES |
|
nRF24L01 |
NO |
YES |
Sample Code For Reference[Github]
If you need technical support please check below link to find more details.
