Mini Ultra Compact 0.97 Inch E-Ink Screen 184×88 Resolution 18PIN FPC SPI Small Epaper Display

Name: Mini Ultra Compact 0.97 Inch E-Ink Screen 184x88 Resolution 18PIN FPC SPI Small Epaper Display
SKU: 1005004332530295
Availability: InStock

Price range: $9.90 through $27.90

Size

Clear

Add to compare

Add to wishlist

Guaranteed Safe Checkout

Features & Compatibility

		0.97-inch Mini E-Ink Display for DIY Projects and IoT Devices
		The GDEM0097T61 is a 0.97-inch e-paper display with a 184×88 resolution and SPI interface. It supports partial refresh and retains images without power, making it ideal for low-power applications. This feature is perfect for battery- or solar-powered devices, such as shelf tags, smart tags, wearables, smart home products, industrial instruments, and smart cards.


	Special Features
	● Ultra-Thin & Lightweight: 0.97-inch e-ink screen, only 0.89g, ideal for portable devices. ● Fast Refresh: Full refresh in 2s, partial in 0.3s for quick updates. ● Bistable Display: Retains images even when powered off for energy savings. ● Wide Viewing Angle: Over 170° visibility for clear display from any angle. ● Eye-Friendly: Anti-glare, no blue light, and zero radiation for healthier viewing.

	Technical Details

Product Specifications

PART NUMBER	GDEM0097T61	CONNECTOR	18 PIN FPC
SIZE	0.97 inch	COLOR	Black, White
TYPE	Dot Matrix	MAX GRAYSCALE	4
IC	SSD1680	4 GRAYSCALE REFRESH(s)	2
PPI	210.27	FULL UPDATE TIME(s)	2
RESOLUTION	184×88	PARTIAL UPDATE TIME(s)	0.3
OUTLINE SIZE(mm)	30.0×14.15×1.0	TYPICAL POWER(mW)	9
ACTIVE SIZE(mm)	22.26×10.65	DEEP SLEEP POWER(mW)	0.003
PIXEL PITCH(mm)	0.121×0.121	INTERFACE	SPI
OPERATING TEMP.	0℃~50℃	STORAGE TEMP.	-25℃~70℃
