Product features:
Input voltage: 8 V to 26 V
Amplifier type: Class D
Number of channels: Dual channel
Output power: 10W+10W
Output impedance: 4 Ω -8 Ω
Efficiency: up to 90%
Sound quality: distortion far below 10%.
Protection: Output short circuit protection, overheating protection. Function self recovery.
Module size: 43 * 55 * 14mm
usage method:
Recommend using 4 Ω -8 Ω speakers with a power not exceeding 10W. The product has the ability of output short circuit protection and overheating protection, and automatically recovers after turning off and restarting. Please refer to the wiring diagram for specific connection usage instructions.
