10.85 Inch E-Ink Screen Four-Color 1360×480 E-Paper Display Black White Red Yellow

Name: 10.85 Inch E-Ink Screen Four-Color 1360x480 E-Paper Display Black White Red Yellow
SKU: 1005007329575299
Availability: InStock

Price range: $92.50 through $110.80

Size

Guaranteed Safe Checkout

		10.85-Inch Four-Color E-Paper Display 1360×480 SPI Interface
		This 10.85-inch Four-Color E-Paper Display – the perfect blend of high-res magic and vibrant hues!This SPI interface wonder is a power-saver, retaining your content without guzzling energy. Enjoy wide viewing angles, anti-glare goodness, and eye-friendly tech – all in one sleek package. Ideal for smart tags, home gadgets, and industrial displays, it’s your go-to for colorful, efficient, and eye-catching screens!

		Special Features
		● High-Res, Vivid Colors: Dive into a 1360×480 resolution with stunning black, white, red, and yellow. Perfect for making your content pop! ● Eco-Friendly Power Saver: Thanks to bistable display tech, it only uses power when refreshing. Your content stays put without draining the battery! ● Wide Viewing Angles & Anti-Glare: Enjoy over 170 degrees of clear viewing from any angle. Plus, our anti-glare surface means you’ll always see clearly, even in bright light. ● Easy Integration with SPI Interface: Seamlessly integrate with your devices. Perfect for smart tags, home gadgets, and industrial displays. ● Eye-Friendly Technology: Say goodbye to blue light and radiation. Our display is designed to be easy on your eyes, even with long-term use. ● Persistent Display: Content remains visible even when the power is off. Ideal for critical information that needs to be displayed continuously.

Technical Details

PART NUMBER	GDEM1085F51	CONNECTOR	24 PIN
SIZE	10.85 inch	COLOR	Black, White, Red, Yellow
TYPE	Dot Matrix	FULL REFRESH TIME(s)	20
PPI	132.92	FAST UPDATE TIME(s)	12
RESOLUTION	1360×480	POWER CONSUMPTION OF THE REFRESH(mW)	66
OUTLINE SIZE(mm)	270.56×105.92 ×1.20	STANDBY POWER CONSUMPTION (mW)	0.003
ACTIVE SIZE(mm)	259.76×91.68	OPERATING TEMP.	0℃~40℃
PIXEL PITCH(mm)	0.191×0.191	STORAGE TEMP.	-25℃~70℃
IC	JD79665AA	INTERFACE	SPI
