| PIXELS |
8 Megapixels |
| SENSOR |
IMX219 |
| CAMERAS |
CMOS size |
1/4inch |
| APERTURE (F) |
2.4 |
| Resolution |
3280 × 2464 (per camera) |
| Focal Length |
2.6mm |
| FIELD OF VIEW |
83°(D) 73°(H) 50°(V) |
| DISTORTION |
< 1% |
| Baseline Length |
60mm |
| ICM20948 |
Accelerometer |
Resolution: 16-bit |
| Measuring Range (configurable): ±2, ±4, ±8, ±16g |
| Operating Current: 68.9uA |
| Gyroscope |
Resolution: 16-bit |
| Measuring Range (configurable): ±250, ±500, ±1000, ±2000°/sec |
| Operating Current: 1.23mA |
| Magnetometer |
Resolution: 16-bit |
| Measuring Range: ±4900μT |
| Operating Current: 90uA |
| DIMENSIONS |
24 × 85mm |
| APPLICATIONS |
AI vision applications like depth vision and stereo vision. |
